Watch & Learn
Product demos, tutorials, industry talks, and conference presentations from the AUV engineering team.
DSIM 2026a Highlights Quick View
See What’s New in Under 3 Minutes: DSIM API for use with Python； New C Block compiler； User feedback channel； Smart element search； Circuit and subcircuit enhancements. Try DSIM 2026a: https://www.dsimtechnology.com/try_dsim
Using C Block in DSIM
This video shows C Block in DSIM. C block allows users to define customized models. It enables users to input C code directly without the need for compilation. This feature simplifies the process of writing custom C code. Know more: https://www.dsimtechnology.com/cdmmk Try DSIM: https://www.dsimtechnology.com/rjsysqb
Power Electronics Simulation Tutorial: Building a Three-Phase Inverter
In this video, we will learn how to quickly build and simulate a three-phase inverter system using DSIM. If you have other topics of interest, feel free to leave a comment in the comment section. Try DSIM and build your circuit: https://www.dsimtechnology.com/rjsysqb.
Electric-thermal Simulation and Loss Calculation with DSIM
In this short video, we are showing that #DSIM can calculate switching losses by simulating the switching transient waveforms of voltage and current. The case (Dual Active Bridge Loss Calculation) includes 8 active switches, with a switching frequency of 20 kHz. It only takes 3 seconds to finish 100 ms simulation.
Non-Ideal Switch Inverter Simulation with DSIM
In this short video, we are showing how fast DSIM can simulate inverter with non-ideal switch models. It only takes less than 1 second to finish 200 ms simulation.
LLC Isolated Bidirectional DC-DC Converter Simulation with DSIM
In this short video, we are showing how fast DSIM can simulate LLC Isolated Bidirectional DC-DC Converter with 8 active switches and 200 kHz switching frequency. It only takes 1 second to finish 100 ms simulation.
SST Simulation with DSIM
In this short video, we are showing how fast DSIM can simulate 50 kVA Solid State Transformer with 24 physical switch models. It only takes 5 seconds to finish 500 ms simulation.
Ideal SST Simulation with DSIM
In this short video, we are showing how fast DSIM can simulate 50 kVA Solid State Transformer with 24 Ideal switches. It only takes less than 1 second to finish 500 ms simulation.
10 kV 2 MW Electric Energy Router Simulation with DSIM
In this short video, we are showing how fast DSIM can simulate 10 kV 2 MW System with 578 active switches and 20 kHz switching frequency. It only takes 13 seconds to finish 100 ms simulation.
9 Level Cascaded H-Bridge Simulation with DSIM
In this short video, we are showing how fast DSIM can simulate 9 Level Cascaded H-Bridge with 48 active switches and 25kHz switching speed. It only takes 0.4 seconds to finish 100ms simulation.
PMSM Simulation with DSIM
In this short video, we are showing how fast DSIM can simulate PMSM Drive with Field-Oriented Control (dead-time included). It only takes 2 seconds to finish 300ms simulation.
